The Phoenix

Fragrance Installation:

1. Power off the diffuser before handling.
2. Attach your 500 mL Scentara fragrance bottle directly to the diffuser base — no pouring required.
3. Once secured, power on and set your desired scent level or schedule using the onboard controls or compatible third-party app.
4. Allow a few minutes for fragrance to disperse evenly through your HVAC system or open space.

Best Practices:

• Only use Scentara fragrance oils (formulated for cold-air diffusion).
• Do not overfill past the bottle’s shoulder.
• Keep the diffuser upright during use and transport.
• For best performance, run 4–6 hours daily.

Uses 500 mL Scentara fragrance oils (screw-in compatible). Each bottle is designed to last between 3–5 weeks depending on settings and usage frequency.

Average performance:

• Low to Medium Settings: Up to 5 weeks
• Daily High Usage: Approx. 3 weeks
• Recommended runtime: 4–8 hours per day

Actual longevity may vary based on scent intensity, airflow, and space size.

Proper care keeps your Phoenix diffuser performing at its best for consistent, even scenting.

Ensure the unit remains upright and securely installed during use. When handling or refilling, make sure your hands are clean and dry to prevent oil residue on the bottle or threading.

Only use Scentara fragrance oils — other formulations may clog the atomizer and void the warranty.

Avoid overfilling beyond the bottle’s neck line, and always power off before removing or attaching bottles.

Keep the diffuser in a cool, dry area, away from direct sunlight or heat sources. Wipe the exterior with a soft, dry cloth — never use solvents or abrasive cleaners.

If oil comes into contact with skin or eyes, rinse thoroughly with water. Keep the diffuser and fragrance oils out of reach of children and pets.

For best results:

• Replace oil every 3–5 weeks, depending on settings and usage.
• Run 4–8 hours daily for consistent performance.
• Allow the diffuser to run for several minutes when switching scents to clear residual oil.

Engineered for large spaces and HVAC integration using precision cold-air diffusion.

• Coverage: up to 3,000 sq ft
• Oil Capacity: 500 mL (16.9 fl.oz.)
• Power: Standard AC plug-in - DC 12 V / 13 W
• Control Options: Built-in programming or compatible third-party app
• Connection: Direct HVAC integration
• Refill: 500 mL bottle screws directly into system
• Material: Aluminum body, matte black finish
• Noise: < 35 dB
• Dimensions: 7.9 × 5.5 × 11.2 in (200 × 140 × 285 mm)
• Weight: 8.6 lb (3.9 kg)

Warranty: Includes a 1-year limited warranty covering manufacturing defects under normal use.

For questions or support: support@scentara.com
